SDEC SC27G755D2 (T2) diesel engine is the SDEC SC27G755D2 engine, built for continuous duty in generator sets and industrial drives.
The engine is supplied as a complete unit for coupling to an alternator, pump or machine: block, head, injection system, water pump and filters already fitted. The SC27G755D2 designation identifies displacement and aspiration layout, so spare parts are ordered by that code rather than by power rating.
Data and compatibility
- Brand
- SDEC
- Model
- SC27G755D2
- Aspiration
- Aspiración natural
- Origin
- China
Technical Specifications
Typical Generator Capacity (50/60 Hz)
| Model | 50 Hz Prime / Standby (kVA) | 60 Hz Prime / Standby (kVA) | Engine Output 50/60 Hz (kW) |
|---|---|---|---|
| SC27G755D2 | 563 / 625 | / / / | 505 / 555 | / / / |
Typical Generator Capacity (50/60 Hz)
| Model | 50 Hz Prime / Standby (kVA) | 60 Hz Prime / Standby (kVA) | Engine Output 50/60 Hz (kW) |
|---|---|---|---|
| SC4H95D2 | 63 / 70 | / / / | 62 / 68 | / / / |
| Parameter | SC25G (610-690D2) | SC27G (755-900D2) |
|---|---|---|
| Aspiration | Turbo & Intercooler | Turbo & Intercooler |
| No. of Cylinders×Bore×Stroke (mm) | 12X135X150 | 12X135X155 |
| Cylinder Liner Type | Wet Liner | Wet Liner |
| Compression Ratio | 16:01 | 16:01 |
| Displacement (L) | 25.8 | 26.6 |
| Speed Governing Rate (%) | ≤5 | ≤5 |
| Rated Power (kW) | 405-459 | 505-602 |
| Rated Speed (rpm) | 1500 | 1500 |
| Standby Power (kW) | 445.5-505 | 560-662 |
| Min. Fuel Consumption (g/kW·h) | 205 | 205 |
| Exhaust Smoke (FSN) | 1 | 1 |
| Lube Oil Capacity (L) | 55-65 | 55-65 |
| Cooling System Capacity (L) | 48 | 48 |
| Engine Oil Consumption (g/kW·h) | ≤0.4 | ≤0.4 |
| Emission Standard | Stage II | Stage II |
| Noise (dB-A) | 115 | 115 |
| Net Weight (kg) | 2200 | 2200 |
| Dimensions L×W×H (mm) | 1930×1686×1872 | 1930×1686×1872 |
| Flywheel Housing/Flywheel | SAE1/2# 14 | SAE0#&18# |
Application
- Standby and continuous-duty generator sets.
- Water pump and irrigation drives.
- Construction, mining and material-handling machinery.
- Repowering equipment whose original engine is no longer supported.
Frequently asked questions
How do I know this engine fits my generator set?
The SC27G755D2 code must match the plate on the installed engine. If you are building a new set, start from the alternator rating and select the engine by speed and torque curve, not by nameplate kW alone.
Does it ship with documentation?
Yes. Every unit leaves with its datasheet and its SC27G755D2 identification code. If your purchase requires a certificate of origin or a conformity certificate, state it in the quotation request so it is issued with the order.
