Diesel generator set - WEICHAI BC-WC138D-50 (110 kW / 138 kVA)
BOCHI POWER Weichai gensets use Weichai WP and 16M engines, covering a wide power band with an extended service network. Integrated and tested by BOCHI POWER.
| Model | BC-WC138D-50 |
| Standby power | 138 kVA / 110 kW |
| Prime power | 125 kVA / 100 kW |
| Engine | WP6D132E201 |
| Frequency | 50 Hz |
| Voltage | Multi-voltage 110/208 - 277/480 V |
| Phases | Three-phase, four-wire |
| Dimensions (mm) | 2400 x 950 x 1510 |
| Type | Open set |
Built, integrated and tested by BOCHI POWER.
Overview
The Diesel Generator Set - WEICHAI BC-WC138D-50 (110 kW / 138 kVA) is a 138 kVA / 110 kW standby diesel generator set, built around a WP6D132E201 engine and open type configuration. It delivers 50 Hz, three-phase four-wire, at 110/208 V – 277/480 V.
At this rating the set backs up a whole building or production line: process plants, industrial units and commercial centres where an outage is not an inconvenience but a production stop with a direct cost. BCP’s Weichai range spans 30 to 4125 kVA with Weichai power, intended for standby duty and for extended running depending on how the fuel and cooling system is specified.
Typical applications
- Industrial units and process plants
- Logistics and distribution centres
- Hospitals and corporate buildings
- Food and beverage plants
- Infrastructure and civil works
Standby and prime ratings
The standby rating (138 kVA / 110 kW) is what the set delivers during a grid outage, for a limited number of hours a year and without sustained overload. The prime rating (PRP) allows continuous duty with varying load. Sizing starts from the real load in kW, corrected by power factor, with headroom left for motor starting.
Frequently asked questions
What is the difference between standby and prime?
Standby is the power available in an emergency, limited to a set number of hours a year; prime is what the set can sustain continuously with varying load. A set sized for standby should not be used as prime generation without re-checking the duty.
What voltage and connection does the BC-WC138D-50 deliver?
It is offered at 110/208 V – 277/480 V, three-phase four-wire, 50 Hz. Final nameplate voltage is fixed at order stage according to the site network and the transfer arrangement.
Is one set of this size better than two smaller ones?
It depends on criticality. A single set simplifies maintenance and footprint; two units give N+1 redundancy but double the capital cost and the service plan.
More from the range
Full Weichai range: Weichai diesel generator sets · all series and ratings · generator set catalogue · request a quote.
Similar power ratings
- BC-WC125D-50 — 125 kVA
- BC-WC165D-50 — 165 kVA
- BC-WC104D-50 — 104 kVA
- BC-WC188D-50 — 188 kVA
Specifications
| Characteristics | |
|---|---|
| Brand | WEICHAI |
| Engine Model | WP6D132E201 |
| Voltage (V) | 110/208V 127/220V 230/400V 254/440V 277/480V |
| Power (kW) | 110 |
| Emission Standards | T 2 |
| Phases | Three-phase four-wire system |
| Generator Set | |
|---|---|
| Generator set model | BC-WC138D-50 |
| Generator set series | Diesel series |
| Generator set structure type | Open type |
| Others | |
|---|---|
| Rating (kVA) | 138 |
